New incubator

[Rango3d]

Installed the flex watt tape and pre-wired for the light. Now time for a test run.



[Rango3d]

Everything working great so far.



[Rango3d]

Did you get the humidistat, and temp control? I was looking at that box myself for a cheap project. It's missing a few features I want though. How accurate? Intuitive?

It's a pretty cheap control. I think I paid 15 bucks for it shipped.
I'm not sure which control it is. It's pretty easy to use. It's been pretty dam accurate so far. I think it was off 1 deg when I got it but your able to calibrate it. Which leaves it dead on.
Hope that helps.



[happy]

its a very nice build... and very clean. before i saw yours, I was scouring Craigslist for a glass door mini so i could do the same thing..



[Rango3d]

Thanks
Still not done. Need to install the lighting and a fan. Still waiting on that stuff.



[Mike Fisher]

STC 1000 same as I use. It reads in Celsius, but you can reflash the firmware with an Arduino to display in Fahrenheit.



[happy]

200 mm fan from microcenter, with lights.... 16$ at microcenter in orange county..... lol...



[Rango3d]

STC 1000 same as I use. It reads in Celsius, but you can reflash the firmware with an Arduino to display in Fahrenheit.

Mine isn't the STC 1000. It already came in Fahrenheit. It's almost the same but the programming is a little different. That's how it came out of the box.
I also have a STC 1000 spare.



[SMCNARY]

Installed the flex watt tape and pre-wired for the light. Now time for a test run.

You will find the 11 inch flexwatt will help keep a steady temp. I afraid that what you are using is to small but I have never tried it with that size so I hope I'm wrong.
Good luck



[Rango3d]

You will find the 11 inch flexwatt will help keep a steady temp. I afraid that what you are using is to small but I have never tried it with that size so I hope I'm wrong.
Good luck

I have the 4" right now. I didn't wanna use flex tape. Surprisingly it's working just fine. I think that the cooler is so well insulated it doesn't matter what I use. It's been hold steady better then I imagined.



[Mike Fisher]

Mine isn't the STC 1000. It already came in Fahrenheit. It's almost the same but the programming is a little different. That's how it came out of the box.
I also have a STC 1000 spare.

Ah, most likely the ITC 1000. I considered that one, but you can't reprogram the PIC on it AFAIK. I can set mine up for temperature cycling/ramping by reprogramming the internal IC. Good for night drop, and also for gentle diapause ramping.
